XTOOL Prodigy Smart Diagnosis Scanner J2534 ECU Programmer Battery Test 51+Rests

XTOOL Prodigy Smart Diagnosis Scanner J2534 ECU Programmer Battery Test 51+Rests

Product Code：

22848 Weight：0.3Kg

Categories: Diagnostic Tools

Price: $ 5350.00

Quantity：

Buy Now

ADD TO CART

Add to Wishlist

Share this：

Product Specification

Manufacturer	XTool
Update	3 years free online update
Warranty	1 year
Weight	0.3 Kg

Overview

XTOOL Prodigy Smart Diagnosis Scanner J2534 ECU Programmer Battery Test 51+Rests

OE level fast diagnostics + J2534 ECU Programming + 4000+ Bidirectional Control + over 50 Service functions
Advanced ECU Onine Offline Coding, PMI function
Topology Mapping, ADAS calibration, Pre & Post Scan, 3-Year Free Updates
IDENTIFIX--Online Informatics Database (For One Year)

XTOOL PRODIGY Flagship Bidirectional Smart Diagnosis System

Prodigy is a high-performance automotive diagnostic tool featuring a 13.3-inch touchscreen, Android 10.0, and advanced communication protocols (DoIP/CAN FD). Designed for electric, gasoline, and hybrid vehicles across global markets, it offers fast diagnostics, 50+ reset and relearn functions, ADAS calibration, and seamless ECU programming. With topology mapping and enhanced diagnostic reports, Prodigy ensures precise and efficient troubleshooting for professionals.

XTOOL PRODIGY Flagship Bidirectional Smart Diagnosis System

Highlights:

XTOOL's first device offering access to an online informatics database in partnership with Autodata
13.3" HD Display (1920 × 1080) with Android 10.0 system
Powered by 2.2GHz + 1.8GHz Octa-core processor with 8GB RAM and 256GB ROM
IDENTIFIX--Online Informatics Database(For One Year)
Dual Wi-Fi modules for simultaneous internet and VCI connection, ensuring uninterrupted online diagnostics. The VCI supports wireless communication up to 10 meters with high-speed stability, allowing reliable DOIP programming and coding without cable constraints
Long-lasting 9600mAh, 7.2V battery for extended diagnostic sessions
Built-in 13MP rear camera for capturing high-resolution images
Supports all standard VCI protocols including DoIP and CANFD
SAE J2534 compatibility for OEM-level software connectivity
Supports 50+ brands and 5,000+ vehicles across U.S., European, and Asian markets
Tesla Diagnostics Available: Perform comprehensive diagnostics on Tesla vehicles with full data access and a range of special functions
Topology module mapping with color-coded full system status (on supported vehicles)
Supports offline programming for Ford, Lincoln, and Mazda
Supports online coding and programming for VAG, BMW, and Mercedes-Benz
Capable of ADAS system calibration for cameras and radars
Includes OBDI connectors and a wireless charging dock that enables instant charging by simply placing the device on the dock
Provides enhanced diagnostic reports: PreSCAN and PostSCAN
3-year software subscription included
AutoAuth™ integration for FCA SGW access
Up To 8 Graphic Live Data

Top Hardward Configuration Make the XTOOL PRODIGY Stand out :

Powered by Android10.0
equipped with 13.3 inch touchscreen HD Display (1920 × 1080)
2.2GHz + 1.8GHz Octa-core processor
8+256 GB storage
9600mAh*7.2V battery Giving you longer battery life, faster speeds, a clearer, sharper screen and a smoother, more comfortable experience.
Come with Charging Base

XTOOL PRODIGY Flagship Bidirectional Smart Diagnosis System

XTOOL PRODIGY Functions

One-Stop ECU Programming J2534 Device Extended Programming Ability for Multi-cars:

XTOOL Prodigy equipped with J2534 device is competent for ECU programming/ECU online coding/adaptation for BENZ/BMW/ect cars. It can program blank ECU, adapt existing EC.U, match components, reflash second-hand ECU, unlock hidden functions, etc.
When using the J2534 function, you do not need a tablet. You only need to use VCI to connect the vehicle and the PC. Currently, only wired connection is supported.
To use the J2534 function, you need to install the XTOOL driver on the PC and then install the original diagnostic software. (NOTE: We do not provide original software)

1) J2534 VCI Application scenarios:

J2534 devices are widely used in auto repair shops, auto manufacturers, and aftermarkets. It enables auto repair personnel to use unified equipment to diagnose and program vehicles of different brands, greatly improving work efficiency.

2) J2534 Supported communication protocols:
J2534 devices support multiple communication protocols, including IS09141, IS014230 (KWP2000), J1850, CAN (IS011898), IS015765, and SAEJ2610. Since 2005, it also supports the J1939 protocol.

3) Advantage of J2534 VCI:

Standardization: The J2534 standard provides a unified diagnostic and programming interface for vehicles of different brands, reducing equipment costs and learning costs.
Flexibility: Due to support for multiple communication protocols, J2534 devices can adapt to vehicles of different brands and models.
Remote function: Some devices that support the J2534 protocol also have remote functions, making remote diagnosis and operation possible.

XTOOL PRODIGY Flagship Bidirectional Smart Diagnosis System

Advanced ECU Coding, Customize Your Cars

Automotive diagnostic scan tool Prodigy features Advanced EC.U c0ding, so you can use it to customize your cars as needed by disabling some unneeded OEM settings (like auto start-stop, chimes, etc), or activating the hidden features pre-Programmed to car computer to get high-end functions

For replacing, match, relearn, recode new E*CU modules,ensuring seamless ECU matching, coding, and personalized car settings. (Fit for VW / for Audi / for Skoda)

Make full use of hidden features or disable car’s annoying functions like Auto Side Mirrors, Disable Seat Belt Alarm Beep.(For BMW/For VW/For Audi/For Skoda/For Toyota/For Lexus/For Scion/For Mazda/For Ford/For Lincoln)

XTOOL PRODIGY Flagship Bidirectional Smart Diagnosis System

51+ Maintenance Services Same as XTOOL IP919MAX/IP919PRO/D9S PRO

1-Oil Reset：Reset service intervals after oil change and turn off the oil light.
2-EPB Reset: Reset brake pads after replacement of brake system.
3-SAS Adjustment: Perform calibration of the steering angle sensor.
4-BMS Reset：Reset the BMS system after replacing the vehicle battery.
5-Throttle Relearn: Enables you to make initial settings to throttle to adjust the amount of air intake.
6-ABS Bleeding: Perform ABS Brake Bleed function to cycle the ABS pump to bleed the air out of the ABS.
7-Injector : Coding injectors after replacement.
8-Gearbox Match: Reset the adaptive shifting points in your automatic Transmission Control Unit.
9-Crank Sensor Relearn：Learn the crankshaft position sensor to ensure normal operation of the engine.
11-TPMS Reset：Reset the tire pressure monitoring system and turn off the tire pressure warning light.
12-Power Balance：Conduct tightness and balance tests on the cylinder and adjust the power balance of the cylinder.
13-Transport Mode：Transportation mode can be released through the diagnostic tool.
14-Coolant Bleeding：Activate the electronic water pump to check for fault points in the cooling system/drain the air in the cooling system.
15-A/F Reset：By flashing the data parameters inside the E#CU, the engine torque is changed to achieve the maximum horsepower of the engine.
16-NOx Reset; 17-Suspension; 19-DPF;20-Tire Size Reset;21-Headlight; 22-Seat Match; 23-EEPROM; 24-ECU Configurations; 25-Stop/Start Reset; 26-Windows Initialization; 27-Airbag Reset; 28-Language Change; 29-Odometer Read; 30-Control Unit Reset; 31-Rain/Light Sensor; 32-A/C Relearn; 33-HV Battery; 34-VGT Relearn; 35-Write VIN; 36-FRM Reset; 37-EGR Relearn; 38-AdBlue Reset; 39-SRS; 40-Clutch Adaption; 41-Speed Limit; 42-ADAS..

XTOOL PRODIGY Flagship Bidirectional Smart Diagnosis System

OE-level Diagnostics Access All Available Modules

Full System Diagnostic with Topplogy Module Mapping: With Topplogy Map for faster full system diagnostic to view the communication structure between modules clearly with all the situation of each system tp read/clear codes, live data PIDs graphing for all vehicle systems including Engine, Transmission, Chassis and Safety control system, Body control system, Communication and Entertainment system, etc.

Read Codes: Read the fault code, fault description, and fault code status within the selected module.
Clear Codes: Clear the fault code in the selected module and turn off the fault light on the meter.
Read Live Data: Reading all the data flow information contained within the selected module.
Read Freeze Frame: Accompanied by fault codes, record the state of fault codes appearing, to provide help for vehicle fault repair.
Read ECU Information: Read the version information, model information, etc. of the selected module

Bidirectional/4000+ Active Test Is Widely Used on Cars to Help Quick Check

With Bi-Directional function,you can output the command into the ECU in order to turn on/off actuators, to find faults in the subsystems of your car effortlessly, without using the vehicle’s control:

Turn on the radiator fan
Compression Test
Open/close windows
Operate mirrors
Turn on/off the lights
Turn on/off the sound horn
Window/Mirror/Door Lock Test ...

Advantage of Topology:

Get diagnostic results in color coded modules at one glance.
Dive into the fault right on the tree mapping.
Prevent “false” fixes by considering all inter-connected modules to boost repair efficiency.
(Topology are not available to all vehicle makes for now. Available for GM, for CHRYSLER, for JEEP, for DODGE, for FORD, for TOYOTA, for NISSAN, for HONDA, for BMW, for BENZ, for HYUNDAI, for MAZDA and more to come.

FCA Autoauth Access Supports More models

XTOOL INPLUS Prodigy Automotive Diagnostic Scanner supports access to the Security Gateway Module on 2018 and For Fiat/Chrysler/Dodge/Jeep vehicles so that diagnostic tools can clear codes, run bi-directional active tests, drive, relearn and even IMMO passwords K-ey programming (PIN extraction and writing), ECU encoding, initialization, ADAS calibration assistance, etc. (No Need FCA 12+8 Cable)

Newly Added Functions-Supports Your Need !!! XTOOL always pursues High Products for you.

Auto VIN & Scan: Quickly figure out Vehicle Identification No. (VIN) to perform fast diagnostic.
Wireless WIFI Connection: Wireless WiFi Connection has a faster transmission speed and a Longer Communication Distance, more free and not limited by the length of diagnostic cable, make work is more efficient
CANFD & DOIP Protocol: With CAN FD protocol covers for GM MY2020+ models,no extra CAN FD adapter needed; With DoIP protocol covers for BMW E/F/G Chassis/Jaguar/Land Rover vehicle makes.
Upgraded Intelligent Live Data 2.0 & Graphing: ✔Combine up to 8 PIDs in one graphing; ✔ Graph up to 8 sensors individually on the same screen; ✔ Support data record/playback; ✔ Export Live Data as CSV File; ✔ More. Up to 8 real-time data PIDs can be viewed at the same time, such as oil pressure, fuel temperature, coolant temperature, transmission oil temperature, fuel trim, O2 sensor, etc., displayed in text or graph form.
Work With Endposcope XV200(Not include): Work with XV200 to help you to inspect areas that is normally inaccessible, make it easier to find the solution.

New Added Diagnostic Report 2.0 & Pre/Post Scan

Diagnostic Report 2.0: Providing versatile features with four types of diagnostic reports, clear visual icons, and a personalized repair shop logo. Enjoy organized categories, custom content selection, and an updated ema!l format for easy sharing, enhancing your overall diagnostic experience
Pre/Post Scan: Featuring comprehensive pre-scan and post-scan capabilities. Pre-scan identifies existing issues and pending DTCs, ensuring no problems are overlooked before repairs. Post-scan confirms all DTCs are resolved, ensuring your vehicle is in top condition.
Pre-scan: A diagnostic scan performed before any repairs or maintenance to assess the vehicle's current condition and identify existing issues.
Provides a complete picture of the vehicle's health prior to service. Uncovers underlying issues that may not be immediately apparent. Helps technicians make informed decisions on necessary repairs and services.

Post-scan:

A diagnostic scan conducted after repairs or maintenance to verify that all issues have been addressed and the vehicle is operating correctly.
Confirms that all diagnostic trouble codes (DTCs) have been resolved and systems are functioning properly.
Generates a detailed report for clients, enhancing transparency and trust.
Ensures that no new faults were introduced during repairs, promoting long-term vehicle reliability.

Prodigy is global version, NO IP limited, 50+ Brands, 20,000+ Vehicle Coverage

XTOOL Prodigy all-in-one diagnostic tool is specially customized for large Maintenance Shops, Workshops, Car Dealers, Auto Mechanic occupies a place in the XTOOL diagnostic series with its excellent Comprehensive Performance. Works on sedans, SUVs, minivans, 12V light trucks, etc.
Note: Supports European, American, and Asian vehicle models, excluding Chinese vehicle models.

Technical Specifications

Operating System: Android 10.0
Processor: Octa-core 2.2 GHz + 1.8 GHz
Memory: 8 GB RAM + 256 GB ROM
Display: 13.3" HD (1920×1080)
Battery: 9600 mAh, 7.2V
Camera: 13 MP rear
VCI Communication: Wi-Fi / Wired (USB-C)
Supported Protocols: DoIP, CANFD, UDS, OBDII, J2534, SAE J1939, SAE J1708, SAE J1850, K-Line, L-Line

Package List:

1 set x XTOOL PRODIGY Flagship Bidirectional Smart Diagnosis System

Notice
