SAAB SCL 9-3 2003-2011 Steering Lock Emulator

Product Code:

27073 Weight:0.04Kg

Categories: Emulators

Price: $ 35.00

Quantity:

Buy Now
ADD TO CART
Add to Wishlist
Share this:
Product Specification
Condition New
Weight 0.04 Kg
Overview
SAAB SCL 9-3 2003-2011 Steering Lock Emulator

SAAB SCL 9-3 2003-2011 Steering Lock Emulator Specs:

Condition: New
Compatible Part Number: 12770232 / 12801116 / 12782933 / 12767697


SAAB SCL 9-3 2003-2011 Steering Lock Emulator Overview

The SAAB SCL 9-3 steering lock emulator is one of the most advanced ESL emulators currently available. SAAB SCL 9-3 steering lock emulator


The SAAB SCL 9-3 module in SAAB vehicles is prone to failure and most SAAB users get steering lock fault issue but the SAAB SCL 9-3 Universal Steering Lock Emulator can be used to eliminate the need for costly replacements.

SAAB SCL 9-3  Steering Lock Emulator requires programming in order to function as a replacement for the damaged steering lock.
When the original ELV unit is available, its data can be read and used directly to configure the emulator.
If the ELV is missing or completely non‑functional, the necessary data may instead be obtained from the vehicle’s BCM and used to initialize the emulator accordingly

  • ELV Is A Self-occurring Mechanical Failure In The Steering Column Lock.
  • The Occurrence Of The Fault Does Not Depend On Any Fault.
  • In Case Of Malfunction, Even If There Is No Problem In The Vehicle Key, The Working Key Will Not Start The Vehicle Because The ELV Steering Column Lock Will Not Be Activated.
  • In This Case, A New ELV Steering Column Lock Must Be Installed In The Vehicle And Programmed Into The Vehicle.
  • Steering Lock Problem Is One Among The Foremost Frequent Problems In SAAB Starting System, SAAB Dealer Need To Order New Steering Lock And Program It Which Is Just Too Much Costly And Required While Of Waiting.
  • Electronic Steering Lock SAAB SCL 9-3 Emulator Will Fix Your Steering Lock Malfunction Error, And Therefore The SAAB SCL 9-3 Steering Lock Emulator Will Bypass SAAB SCL 9-3 always.
    Require Coding , And It'll Fix Your SAAB SCL 9-3 Fail

SAAB SCL 9-3 2003-2011 Steering Lock Emulator Steps:

To program the emulator, the data can be read using one of the following two methods:



Method 1: Read the ECM dump from the CIM (93LC66) EEPROM.



Method 2: Read the Steering Lock (SCL) EEPROM dump (24C04).

Once the data has been read, write it directly to the emulator.

Then simply install the emulator and start the vehicle.


SAAB SCL 9-3 2003-2011 Steering Lock Emulator Key Features

  • Fast and easy programming process.
  • Programming completed in just a few minutes.
  • Works as a replacement for the original ESL after programming.
  • No complex manual data editing required.
  • Reliable and professional solution for repairing steering lock failures.

  • SAAB SCL 9-3 2003-2011 Steering Lock Emulator LED Status Indicators

    • Red LED: Steering Column Lock is in the LOCKED position.
    • Green LED: Steering Column Lock is in the UNLOCKED position.

    Whenever the SCL receives power, one of these LEDs will indicate its current status.


Note:

Repeated lock/unlock attempts while the vehicle is stationary may temporarily disable the steering lock. The function will automatically recover after driving above 20 km/h (12 mph).


SAAB SCL 9-3 2003-2011 Steering Lock Emulator Lock + Plug:
